Mishimoto's Universal Intercoolers are designed to fit into whatever space you need them to under your bonnet. Sold in a range of sizes, all use robust aluminium construction and efficient core design to make the most of the space on offer.
- Robust aluminium design
- Size efficient core design for optimal cooling
- Range of useful sizes
In addition to their vehicle specific intercoolers, Mishimoto offer a range of universal intercoolers.
Sold in a variety of sizes to fit whatever space is available under the bonnet, these are all constructed from 6061 aluminium and come with the Mishimoto Lifetime Warranty.
Mishimoto use a highly efficient tube and fin core design to get the maximum possible cooling from even the smallest of these intercoolers.
All intercoolers come 6061 aluminium construction, cast end-tanks, 4 universal mounting points.
These are available in a range of sizes:
| Type | Overall Width | Overall Height | Overall Length | Core Width | Core Height | Core Length | Inlet / Outlet |
| Z-Line | 2.5 | 7.5 | 28 | 2.5 | 6.25 | 20.5 | 2.5 |
| S-Line | 3 | 12 | 31 | 3 | 12 | 23 | 3 |
| R-Line | 4 | 12 | 31 | 4 | 12 | 24 | 3 |
| M-Line | 3 | 11.75 | 31 | 3 | 11.75 | 23.5 | 3 |
| J-Line | 3.75 | 7.5 | 29.5 | 3.75 | 7.2 | 22 | 2.5 |
| G-Line | 3 | 11.75 | 24.5 | 3 | 11.75 | 24.5 | 3 |
